4. INSTALLATION INSTRUCTIONS

Before using your wine cellar
•
Remove the inner and outer packaging.
•
Before connecting the cellar to the electrical socket, leave it in position for 24 hours. This will reduce the
possibility of malfunction of the refrigeration circuit due to transport.
•
Clean the inside using a soft cloth and lukewarm water.
Using your wine cellar:
Your wine cellar must be positioned in a room with an ambient temperature between 16 and 32°C.
Alternatively, if the cellar is fitted with the winter system, the range is extended to 0 to 32°C
Installing your wine cellar
•
This wine cellar is designed for free-standing installation.
•
Position it in a place with sufficient strength to support its weight when loaded.
•
To get the best from your appliance with the lowest energy consumption, do not place the appliance
close to a heat source (heater, cooker, etc.), do not expose it to direct sunlight, and do not place it in a
room which is too cold.
•
Connect the cellar to a single socket, leaving a 10 cm gap between the back of the cellar and the wall.
Ensure that your wine cellar is perfectly horizontal, then slightly raise the two front feet. (Use of a spirit
level is recommended). This will prevent any movement due to instability, causing noise and vibration,
and will ensure that the door seals perfectly.
Adjusting the thermostat
Important note: All temperatures shown in this manual are temperatures read in the wine, inside the
bottle.
Tip: immerse a suitable thermometer in a clear glass bottle filled with water and place it in the middle of
the cellar. Wait at least 24 hours before checking the temperature. Then adjust the thermostat in the light
of the temperature read and that required.
Key to select in order to set the temperature
The thermostat in your wine cellar only controls the production of cold air. If your wine cellar is equipped with the
winter system and is intended for use in an unheated area, the heating circuit is factory preset and you do not
need to adjust it.
The temperature setting is possible between 8°C and 18°C (at a recommended room temperature of 25°C).
When the fan is activated, the temperature will be similar within the whole cavity according to your setting.
When the fan is deactivated, for a temperature sets at 12°C, the temperature will be 12°C plus or minus 3°C
between the top and bottom. For example if you set the temperature at 12°C, the bottom temperature will be
between 9°C and 12°C, and the top temperature will be between 12°C and 15°C.
To activate or deactivate the cooling fan, please use the on/off switch located on the left side of the control board.
Key to increase the temperature
Key to decrease the temperature
Key to activate or deactivate the light
22
