EN
E-02 I2T Fault
E-0 Motor Stall
E-04 Over Current
E-05 Over Temperature
E-06 Current Off set Fault
E-0 Shunt Calibration Fault
E-08 Torque Offset Fault
E-09 Transducer Fault
E-0A Step Execution Timeout
E-0B Configuration Execution Timeout
E-0C Over Torque Limit
E-0D Over Angle Limit
E-0E Current Plausibility High
E-0F Under Torque
E-10 Under Angle
E-11 Current Plausibility Low
E-12 Early trigger Release
E-1 Motor Controller Watch dog Reset
E-14 Brake Timeout
E-18 Missed Run Steps (Prevailing Torque configuration did not complete)
E-1B Battery Cell Fault (detected by Motor Controller)
E-1C Low Battery Fault (detected by Motor Controller)
E-1D Critical Battery Fault (detected by Motor Controller)
E-1E Motor Controller is shutting down
E-1F Wakeup Code received (but not expected)
E-81 The configuration ID in the Motor controller's EOR did not match the currently selected configuration
2-<Alarm ID> PM Alarm Time Fault for corresponding Alarm ID normally configured by the user
-<Alarm ID> PM Alarm Cycle Fault for corresponding Alarm ID normally configured by the user
C-16 Number of configuration steps is set to 0
Parts and Maintenance
Original instructions are in English. Other languages are a translation of the original instructions.
Tool repair and maintenance should only be carried out by an authorized Service Center.
Refer all communications to the nearest Ingersoll Rand Office or Distributor.
EN-20 48619852_ed1
