Appendix 1 : Status LED Definitions
There are four LEDs on the display module.  on the top and 1 below the display screen.
The Status LEDs shall be used as follows:
Red -- The last tightening cycle exceeded its high limit.
Yellow -- The last tightening cycle ended below its low limit.
Green -- The last tightening cycle ended between its high and low limits.
Blue -- The tool has an active fault condition.
Appendix 2 : Tool Fault codes
The tool shall report the following fault codes for the listed conditions:
F-01 Tool Disabled (by external control)
F-02 Rapid Trigger pull – trigger was pulled before configuration delay was complete
1-FF USB enumeration fault
A-10 Motor controller communication timeout
A-55 A display software version update was detected
B-01 Failure to update Motor Controller Software
B-85 RF ACK Timeout (we did not get a serial ACK messages from the transceiver)
B-E1 RF Transmit NAK–"Channel Access Failure"
B-E5 RF Transmit NAK–"Frame Too Long"
B-E9 RF Transmit NAK–"No ACK Received"
C-01 Configuration ID value is 0 or greater than 8
C-02 Number of configuration steps is greater than 8
C-0 Current Step ID is greater than the current number of steps
C-04 Total Gang is greater than 8
C-05 Current Gang count is greater than Total Gang
C-06 Current Torque High Limit is greater than the Tool's maximum Torque value (Tool's max torque value
is configured in the Factory Set Points) OR Current Torque High Limit is less than 0
C-0 Current Torque Low Limit is greater than the Tool's maximum Torque value OR Current Torque Low
Limit is less than
C-08 Current Torque High Limit is less than Current Torque Low Limit
C-09 Current Torque Low Limit is greater than Current Torque High Limit (Fault code to be removed)
C-0A Current Angle High Limit is greater than the Tool's maximum Angle value (to be set to 9999)
C-0B Current Angle Low Limit is greater than the Tool's maximum Angle value (to be set to 9999)
C-0C Current Angle High Limit is less than Current Angle Low Limit
C-0D Current Angle Low Limit is greater than Current Angle High Limit (Fault code to be removed)
C-0E Tool configuration step is a Target torque and the target value is outside the torque high and low limits
C-0F Tool configuration step is an Target Angle and the target value is outside the angle high and low limits
C-10 Tool configuration step is not set for either Angle or Torque
C-11 Current Threshold value is greater than the maximum tool torque OR Current Threshold value is less than 0
C-12 Current Free Speed is greater than maximum motor speed
C-1 Current Shiftdown Speed is greater than maximum motor speed
C-14 Current display unit value is unsupported
C-15 Torque Threshold exceeds target (with torque target) or max torque (with Target Angle)
C-55 Invalid Configuration selection
E-00 Battery Fault
E-01 Invalid Hall State
