3. TECHNICAL DATA

3.1 Table of technical data and mark
The CE mark certifies that the actuator conforms to the essential health and safety requirements laid down
by European product directives. The CE mark can be identified by the relevant adhesive label applied to the
outside of the product, on which are shown some of the data shown in the following table:
Model
Power supply VAC
Frequency
Operation
Push strength
Pull strength
Stroke speed unloaded
Protection class
Double insulation AC
Motor voltage VAC
Loaded power
Operating temperature
Strokes
Strokes setting
Soft Start / Soft Stop
Obstacle detection
Cabling included
Dimensions
***
B00 black version
W00 white version
G00 grey version
SMART
MSMART20H0***
230VCA
50Hz
S2 4min
200N
250N
16 mm/s
IP20
yes
0,14 A
22 W
-5° / +50°
180 - 380
with dip-switch
yes / yes
yes
0,5 m
265x79x41 mm
MSMART20L0***
24VDC
50Hz
S2 4min
200N
250N
16 mm/s
IP20
yes
0,9 A
22 W
-5° / +50°
180 - 380
with dip-switch
yes / yes
yes
0,5 m
265x79x41 mm
