E N G L I S H
EDGEBANDER EB10C
1. SAFETY INSTRUCTIONS FOR
OPERATING THE EDGEBANDER
Read carefully the brochure GENERAL
SAFETY INSTRUCTIONS supplied with the
machine's documents.
1.1 The machine must be secured to a workbench, fixing its
base in position by means of the holes provided.
1.2 Before plugging it in, check that the mains voltage
matches that shown on the specifications plate.
1.3 Always keep your hands away from the cutting areas
and the hot areas.
1.4 Always use original VIRUTEX spare parts. Never use
damaged blades or ones in poor cutting condition.
1.5 When performing any operation involving handling the
machine, unplug it from the mains.
1.6 The cable and plug should be kept in good condition.
1.7 Keep the blades and the entire board running path free
of edging-strip trimmings to prevent blockages.
2. TECHNICAL SPECIFICATIONS
Input power............................................................................2,300 W
Weighted continuous noise pressure equivalent.....82.4 dB(A)
Min. edging thickness..............................................................7 mm
Max. edging thickness.........................................................65 mm
Outer radius.......................................................................unlimited
Min. inner radius.....................................................................55 mm
Electronic temperature control.................................0-500°C
Packing dimensions.........................................930x475x515 mm
Weight.....................................................................................39.1 kg
3. TECHNICAL SPECIFICATIONS
AK97NW TRIMMING UNIT
Input power...................................................................500 W
Motor................................................................................50/60 Hz
Weighted continuous noise pressure equivalent.......82.6dB(A)
No-load speed.........................................................3,200/min
Blades diameter..............................................................38 mm
Min. edging thickness......................................................7 mm
Max. edging thickness........................................................65 mm
Weight.................................................................................4.1 kg
4. STANDARD EQUIPMENT
When opening the crate, you will find two cardboard boxes
inside, containing the following items (Figs. 1 & 2):
A 3833082 Moveable supporting section
B 3833085 Seating washer
C 9075003 Allen bolt M.8x35
D 3821046 Extender shaft
E 3821049 Moveable supporting arm
8
F 1650024
G 1650069
H 8070027
I 1650033
These items must be assembled as shown in (Figs. 1 & 2).
5. DESCRIPTION AND START-UP
5.1 MOVEABLE SUPPORT UNIT
Insert the moveable supporting arms E (Fig. 3) into the
guides J fitted on the sides of the table, leaving them free
to move.
One of the ends of the arms E has the bolt C, the washers
B and the shaft D.
Remove the bolts C and the washer B from the supporting
arms E.
Fit the moveable section A in the supporting arms E and fix
in place with the washer B and the bolt C (Fig. 4).
Move the supporting unit A until it meets the table section
K. Tighten levers L.
Loosen bolts C, bring section A flush with section K and
retighten bolts C.
Loosen levers L and check the movement of the unit in
the guides.
5.2 FITTING THE TAPE ROLL LOADER
Fit the loader unit bracket in place using bolts H. Attach
the loader F into the support shaft. Check the tape entry
height, adjusting it with bolt G (Fig. 5).
5.3 LOCATION AND START-UP
The machine must be placed on a workbench, its base being
fastened down using the holes provided (Fig. 6).
The machine has a STOP-START switch M (Fig. 2) fitted on
the back. This switch provides protection against involuntary
starting-up of the machine, and also acts as the power
intake, the machine being connected to the mains by way
of an earthed extension cable with conductor cables of a
suitable type for a rated current of 16 A.
Place the preglued tape reel in the feeder F (Fig. 5), the
width of the tape matching the board to be edged. It is
advisable to choose a preglued tape whose width is 3 mm
greater than the board width.
-1
Pass the end of the tape roll through the drawing rollers
N, via the channeler P (Fig. 1), the latter having been
preadjusted so that the tape slips through without jamming
and with consistent play.
Using knob R located on top of the feeder reel S (Fig. 1)
(Fig. 9), feed the tape through until it goes into the guides.
Using knob T (Fig. 9) located in the middle of the guides,
move the upper tape guide up or down until the tape runs
freely with the least possible play. The lower tape guide is
Quantity
factory-set to provide enough excess material to enable
1
the board to be trimmed later on.
2
The EB10C model comes from the factory complete with
2
the motorized trimming unit, being necessary to adjust the
2
blades U (Fig. 7) when adjusting the tape width.
2
The control panel is located on the front of the machine,
Tape roll loader
Feeder support unit
Aut. bolt
Presser set
1
1
2
1
