RISERVATO AL PERSONALE AUTORIZZATO ALL'INSTALLAZIONE - ONLY FOR INSTALLATION-AUTHORIZED STAFF
MODELLO
MODEL
RAV4300 - RAV4300DC
RAV4350 - RAV4350DC
RAV4351
RAV4355
RAV4400
RAV4401 - RAV4401DC
RAV4405
RAV4501
RAV4501L
RAV4800 - RAV4800DC
RAV4650 - RAV4650DC
34
A B C
4280 3770 4440 2755
4430 3920 4593 2805
4580 4070 4800 2955
4980 4470 5144 2955
4980 4470 5245 3155
4580 4070 4910 3155
4980 4470 5353 3355
5000 4490 5370 3355
5200 4690 5537 3355
6174 5564 6443 3780
5330 4720 5730 3780
0700-M001-0
D E F
2345 230 180
2395 230 180
2545 230 180
2545 230 180
2745 230 180
2745 230 180
2945 230 180
2945 230 180
2945 230 180
3250 280 240
3250 280 240
FIGURA 6
G H I L
230 280 4360
230 280 4510
230 280 4660
230 280 5060
230 280 5200
230 280 4660
230 280 5060
230 280 5080
230 280 5380
290 330 6255
290 330 5410
RAV4300-RAV4350-RAV4351
RAV4355-RAV4400-RAV4401
RAV4405-RAV4501-RAV4650-RAV4800
M
2805
2835
3005
3005
3205
3205
3405
3405
3405
3830
3830
