Inhaltsverzeichnis - Bernard Controls AQ SWITCH RANGE series Handbuch

1 SAFETY ---------------------------------------------------------- 3
2 PACKAGING, STORAGE AND MAINTENANCE----------------- 3
Packaging
Storage
Maintenance
3 ASSEMBLY ------------------------------------------------------- 5
Changing closing direction indication
4 EMERGENCY HANDWHEEL OPERATION ---------------------- 6
5 ELECTRICAL COMMISSIONNING ------------------------------- 6
5.1 Connection and preliminary tests
5.2 Position feedback potentiometer (OPTION)
5.3 TAM position transmitter (OPTION)
5.4 Heating resistor
6 TRAVEL LIMIT SETTINGS------------------------------------- 11
Single cam setting
Cams and mechanical stops setting
7 TORQUE LIMITING DEVICE (AQ25 / 30 / 50 only) -------- 14
TABLE OF CONTENTS
3
4
4
6
7
7
12
15
