CARE AND MAINTENANCE
CARE AND MAINTENANCE CARE AND MAINTENANCE
HUMIDIFYING FILTER / TRAY
HUMIDIFYING FILTER / TRAY
Odour occurrence may be suppressed when washing Humidifying Filter and Humidifying Tray with water
carefully even if the Filter Indicator Light is not ON.
Remove the Humidifying Filter from the Tray.
Pull up
1
Turn the handle down on
the reverse side.
CAUTION
Rinse the Humidifying Tray, the Filter Frame and the Humidifying Filter.
2
CAUTION
KC-F32EU_OM_WEST.indb 14
Turn down
Remove the Filter Frame.
• Drops of water may drip from the Humidifying Filter and the Filter Frame.
Float
Humidifying Tray Float (Styrofoam)
• Do not remove the Floats.
• If the Float comes off from the Humidifying Tray, install it in the order shown below.
Cross-Section
Tab
view
3. Insert the tab on the
other side of the float
into the hole.
Remove the Humidifying Filter.
Filter Frame
1. Insert the float
under this tab.
Float
E-12
E-14
Remove
Open
Humidifying Filter
2. Insert the tab of the
float into the hole.
