Danfoss AFP/VFG 2 Installationsanleitung Seite 4

Installation Guide
❿
①
⓬
⓭
⊕
4
DEN-SMT/SI
AFP/VFG 2(21) DN 15-250
②
①
①
②
⓫
VFG 2(21)
DN
15
20
25
32
40
50
65
80
100
125
150
200
250
L
A
VI.CA.K2.1I
L
L
L B Weight
mm (kg)
130 212 7
150 238 9
160 238 10
180 240 13
200 240 17
230 275 22
290 275 33
310 380 41
350 380 60
400 380 79
480 326 85
600 354 145
730 404 228
VFG 2 t
= 200 °C
max
L
B
1
DN
mm
150 630 480
200 855 600
250 1205 730
AFP A H
(mm 2 ) mm
80 172 430
250 263 470
630 380 580
District Energy
Weight
(kg)
140
210
300
Weight
(kg)
7,5
13
28
