EQUIPMENT DESCRIPTION

2. EQUIPMENT DESCRIPTION
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19. a. Filter (40 μm) and water trap
19. b. Filter (5 μm) and water trap
20.
21.
22.
23.
The compressor contains of an oil-free piston (16) driven by a low-maintenance single-
phase electric motor. Compressed air is cooled in the cooler (23) where condensed water
is separated into a separate tank (14). Incoming air passes through two filters (15, 21)
undergoing double filtration as it passes through the system (19). The model with a
membrane dryer is intended for applications that require a higher level of air dryness.
Constant outlet pressure is maintained by pressure regulator (20). The built-in air tank (18)
enables peak air consumption of 200 L/min.
The device may be used as a standby compressed air source. In this configuration, the
respiratory equipment is supplied with compressed air from the central compressed air
lines of the medical facility. Air pressure in the central compressed air line is monitored by
a pressure sensor. If the pressure is sufficient, the compressor stays in STANDBY mode.
If the pressure falls, the control unit automatically puts the compressor into operation.
When the compressor is used as the main source of air, the control unit determines its
operation according to the current demand for air. If air consumption is zero, the device
switches to STANDBY mode.
The compressor is equipped with indicators for outlet pressure (1), operating hours (6),
power status (8), drying status (4) and battery condition (7). Acoustic and optical alarms
activate to warn of high operating temperature (3), low outlet pressure (2) and loss of
power (5).
Display – the primary display indicates outlet pressure
PRESSURE - alarm at low outlet pressure
TEMP - alarm at high operating temperature
DRYING – indicates drying level; yellow = unsatisfactory, green =
satisfactory
MAINS – loss of power alarm
TIME – hours of operation are displayed when the button is pressed
BATTERY – low battery indication = yellow
POWER – device status indicator = green
OUT – compressor outlet air
WALL - inlet air coming from an outside compressed air source
Main inlet, power switch, primary fuses
Equipotential (ground) pin
Socket for the electrical cord
Condensate tank
Air intake filter
Compressor
Safety valve
Air tank
Pressure regulator
Intake filter
Control electronics
Cooler
