On / Off Switching
Connect / Installation
Download grandMA2 onPC -software from MA – Homepage.
MA onPC command wing needs software grandMA2 onPC V 2.5.5.0 and higher
(grandMA1 onPC is not applicable).
Install the software „grandMA2 onPC" on your Windows – PC or notebook. Minimum
requirements you will find at: www.malighting.com .
switch on your PC or notebook and start MA onPC.
Connect the command wing to your PC or notebook via the provided USB cable.
Connect the power supply. The command wing is equipped with a automatic PSU (90 -264V ∼//
Connect your PC or notebook with the other hardware. Such as shown on previous page.
50 – 60Hz). PAY ATTENTION TO DETAILS ON PAGE 28 AND 34
ON
Set the mains switch on the rear side of the command wing to „I".
Fader- and DMX -configuration:
From grandMA2 onPC version 2.5.5.0: The faders of the command wing are fixed to numbers 1
till 6. DMX – outputs are also fixed to universes 1 and 2. This version supports 1x MA onPC
command wing or 1x MA onPC command wing + 1 x MA onPC fader wing.
grandMA2 onPC version 2.8 and higher: Fader – numbers and DMX – outputs can be assigned
user-defined in the SETUP – menu of the onPC. This version supports 1x MA onPC command
wing or 1x MA onPC command wing + 1 or 2x MA onPC fader wing.
Note: Flashing executor buttons indicates, that the position of this fader does not correspond with
the position of the virtual fader (internally stored fader position) of the onPC. Position of the
virtual fader is relevant for value output. After first movement of the command wing –fader (the
"real" fader), this position is relevant for value output.
OFF
Set the mains switch on the rear side of the command wing to „O".
Note: Disconnecting the MA onPC command wing from your PC or notebook is always possible
– however DMX –output is interrupted immediately.
Show is always stored on yourPC or notebook, not on your onPC command wing.
Update only possible with a PC or notebook and grandMA2 onPC.
For longer non use disconnect all cables.
