Limits
Connect MA onPC command wing or MA onPC fader wing to your PC or notebook; use the provided
USB 2.0 – cable. For all other hardware e.g mouse, keyboard, use another USB- port.
Available parameters / DMX OUT ports:
PC + MA onPC command wing:
PC + MA onPC command wing + 2Port Node
PC + MA onPC command wing + 2Port Pro Node
PC + MA onPC command wing + NSP (as 4-Port Node)
PC + MA onPC command wing + NPU (as 8-Port Node)
PC + MA onPC fader wing
PC + MA onPC fader wing + MA onPC command wing
MA Lighting offers a bunch of possibilities to expand your parameter count for grandMA2 onPC. All
products in the "MA onPC" range are capable of adding parameters. It depends on you, which products
you would like to combine and how many parameters you need. There are just two simple rules that
need to be followed:
First rule:
The maximum parameter count with grandMA2 onPC is 4,096 parameters.
Second rule:
In any combination MA 8Port Nodes onPC, MA 4Port Node onPC, MA 2Port Node onPC/PRO as well
as MA onPC command wing and MA onPC fader wing will add parameters up to this maximum.
For example: grandMA2 onPC + MA onPC command wing (2,048 parameters) + MA 2Port Node onPC
(512 parameters) + MA 2Port Node onPC PRO (1,024 parameters) = 3,584 parameters
2048 Parameter / 2 DMX OUT
2560 Parameter / 4 DMX OUT
3072 Parameter / 4 DMX OUT
4096 Parameter / 6 DMX OUT
4096 Parameter / 10 DMX OUT
2048 Parameter / 4 DMX OUT
4096 Parameter / 6 DMX OUT
