3. Dimensions

4 Technical Data

4.1

General

Light intensity *
Light source
Service life
Duty cycle
Ingress protection
Impact strength
Protection class
Operating temperature
Storage temperature
Relative air humidity
Cable inlet
Connecting terminals
Housing material
Lens material
Installation position
Lens colors
* The light intensity may be reduced depending on the lens color and operating mode.
08/2019
Operating Instructions Quadro LED-TL
max. 75 cd (Blondel + Rey)
4 high-performance LEDs
- 30 °C .... + 55 °C
Cage clamp 0.08 – 2.5mm² / 28 – 14 AWG (solid/ fine stranded)
Polycarbonate (PC), light grey RAL 7035
Polycarbonate (PC)
Standard color sequence: red (1), yellow (2), green (3)
page 2 / 6
M16/ M25 cutout prepared
Cable gland M20x1,5
Drilling pattern
recommended mounting bores
> 50,000 h
100%
IP 66 (EN 60529)
IK 08 (EN 50102)
II
- 40 °C .... + 70°C
95 %
1x M20x1,5
any
086200010
