Mounting Bracket - Alpine CDA-7990R Hinweise Über Die Installation Und Anschlüsse

3
Slide the CDA-7990R into the dashboard. When the unit is in place, make sure the locking
pins are fully seated in the down position. This can be done by pressing firmly in on the unit
while pushing the locking pin down with a small screwdriver. This ensures that the unit is
properly locked and will not accidentally come out from the dashboard. Install the Detachable
Front Panel.
Removal
1 Remove the detachable front panel.
2 Use a small screwdriver (or similar tool) to push the locking pins to the "up" position (see
above drawing). As each pin is unlocked, gently pull out on the unit to make sure it does not
re-lock before unlocking the second pin.
3 Pull the unit out, keeping it unlocked as you do so.
< JAPANESE CAR >
6
-EN
Lock pin
CDA-7990R

Mounting Bracket

Front Frame
Screws (M5 x 6)
(Included)
