4 - i
Dimensions for a technical door:
A maxi
A mini
B
C mini
Changing the hinges
1
Loosen the three screws using the Torx "T25" tool.
2
Remove the upper hinge.
3
Remove the grommets gently using a fine blade.
Precautions: If you lift off the glass door of the cabinet, never place it on
28
its edges which may cause it to break.
GB
nstAlling your Wine cABinet
059 259
853 1813
837 1797
548 565
842 1802
•
Fit the hinge with pin
to the cabinet.
•
Fit the hinge without pin
1
2
3
Precautions: When closing the door, check that the seal adheres
correctly to the cabinet so that it is airtight.
B
C
A
B
using the screws so that the door is parallel
A
with the screws.
5
4
7
6
B
A
