Description Of Your Wine Cabinet - Eurocave Compact 59 series Gebrauchsanweisung

1 - d
A
B
C
D
E
F
G
H
J
K
L
M
A
Control and adjustment panel
B
Light (2 leds)
C
Location of temperature probe in 1 temperature
models
D
Air circulation hole + Active carbon filter
E
Sliding shelf
F
Closing clip
G
Storage shelf
H
Grid
J
Humidity cassette (1 temperature models)
K
Power lead
24
GB
escription oF your Wine cABinet
L
Base with front ventilation
M
Filter access grille + aeration filter
N
4 adjustable levelling feet
P
Lower hinge (x2)
Q
Specification label
R
Location of temperature probe in multiple
temperature models
S
Free air circulation hole
T
Door (fitted with handle and a double movement
lock)
U
Upper hinge
U
T
R
S
R
Q
P
N
