Connection of an HDMI Device (Android device)

USB connector HDMI input connector*
USB extension cable
(Included)
• A connection kit or adapter kit suitable for the type of terminal on the connecting device is required.
• Set the HDMI Setup to "HDMI. " For details, refer to "HDMI Setup" in the OWNER'S MANUAL (CD-ROM).
* When connecting an HDMI connection cable, be sure to secure it using the supplied HDMI Fixation Bracket. For details on how to secure it, see "Note on
using HDMI Connection Cables" (page 4).
HDMI connection kit KCU-610HD (sold separately)
HDMI connection cable
Micro USB conversion cable
MHL connection kit KCU-610MH (sold separately)
HDMI connection cable
Micro USB conversion cable
Android device with
HDMI connector
(sold separately)
HDMI Type-D
conversion adapter
Android device with
MHL connector (sold
separately)
MHL conversion adapter
11
-EN
