The Rear Panel at a Glance

Figure 1-3
1
2
3
4
5
6
7
8
9
10
10
3
1 2
Rear panel at a glance
Serial Interface Connector
USB Interface Connector
GPIB with Option 3445GPBU installed
Current Fuse
Model and Serial Number Label
Kensington Lock
Chassis Ground Lug
AC Power Connector
AC Line Fuse
AC Line Voltage Selector
4 6
7
5 7
Keysight 34450A Quick Start Guide
10
8 9
