Initial Operation; Electrical Connection; Maintenance - Scheppach Woova 3.0 Originalanleitung

Note safety instructions before operation.
The data on the motor type plate (voltage and fre-
quency) must conform to the mains supply voltage
and frequency. After connection to the mains, the
Dust Extractor Woova 3.0 is ready for operation.
Connection and repair work on the electrical
equipment must be carried out by a qualified
technician only.
The installed electric motor is factory connected
ready for operation.
The connection made by the customer as
well as any extension cables used must
comply with all relevant regula tions.
Importand note
Defective electrical connection cables
Electrical connection cables often suffer isolati-
on damage.
Possible causes are:
• Pinch points when connection cables are ..
run throught window or door gabs.
• Kinks resulting from incorrect attachment of
laying of the connection cable.
• Cuts resulting from running over the con- ...
nection cable.
• Isolation damage resulting from forcefully ..
pulling out of the wall socket.
For all maintenance and cleaning tasks, tum
off motor and unplug mains.
• Connection and repair work on the electri- ..
cal installation may be carried out by a
qualified electrician only.
• Filter bag
Part. no. 7500 1019
• Filter cartridge
Part. no. 7500 6000
• Reusable sawdust bag
Part.no. 7500 1500 20 pc.
• Extension coupling
Part. no. 7500 3300

Initial operation

Electrical connection

Such defective electrical connection cables
must not be used as the isolation damage
makes them extremly h a z a r d o u s.
Check electrical connection cables regularly for
damage. Make sure the cable is disconnected
from the mains when checking.
Electrical connection cables must comply with
the regulations applicable in your country.
One phase motor
• The mains voltage must comply with the ....
specification on the motor name plate.
• Extension cables must have a cross section
of at least 1.0 sqmm.
• The mains is protected by a 16 A slowblow
fuse.
Three phase motor
• The mains voltage must comply with the
specification on the motor nameplate
• Mains connection cable and any extensions
must be 5-lead cables = 3P + N + PE

Maintenance

• For constant performance, periodi
cally shake out filter bag vigorously. Bet-
ween cleanings, beating the bag with the
....... hand several times is sufficient.
Special accessoires
11
• Extension cables must have a cross section
of at leas 1,5 sqmm
• The mains is protected by max. 16 A
• When connecting to the mains or relocating
the machine, check the direction of rotation
and change polarity if neccessary
(wall socket)
When making inquiries please specify the
following:
• Motor manufacturer
• Motor current type
• Motor nameplate specifications
• Switch nameplate specifications
When sending the motor in, always send the
complete drive unit including the switch.
............... • The sawdust bag must be replaced a1 the .
..... latest when the sawdust is within 10 cm. of
... the housing collar.
D GB
