Starting The Engine; Driving The Tractor - Snapper RDLT Serie Bedienungsanleitung

Starting the Engine

WARNING
Fu4l 0n3 8ts v0pors 0r4 4xtr4m4ly l0mm01l4 0n3
explosive.
Fire or explosion can cause severe burns or
death.
When Starting Engine
• Ensur4 t70t sp0rk plu6, mul4r, 5u4l 20p, 0n3 08r
cleaner (if equipped) are in place and secured.
• Do not 2r0nk 4n68n4 w8t7 sp0rk plu6 r4mov43.
• î5 4n68n4 loo3s, s4t 27ok4 85 4qu8pp43 to OPEN/RUN
position, move throttle (if equipped) to FAST position
and crank until engine starts.
WARNING
En68n4s 68v4 of 20r1on monox834, 0n o3orl4ss,
colorless, poison gas.
Breathing carbon monoxide can cause nausea,
fainting, or death.
Fire or explosion can cause severe burns or
death.
• St0rt 0n3 run 4n68n4 out3oors.
• Do not st0rt or run 4n68n4 8n 4n2los43 0r40, 4v4n 85
doors or windows are open.
1. Check the oil level. See the Checking/Adding Oil
section.
2. Make sure equipment drive controls are disengaged.
3. Move the throttle/choke control to the CHOKE
position.
NOTE: Choke is usually unnecessary when restarting a
warm engine.
4. Insert the key into the ignition switch and turn it to the
ON/START position.
5. After the engine starts, move the throttle/choke
control to the FAST position. Warm up the engine by
running it for at least a minute before engaging the
blade rotation control or driving the rider.
6. After warming the engine, Always operate the rider
with the throttle/choke control in the FAST position.
en
In the event of an emergency the engine can be
stopped by simply turning the ignition switch to STOP.
Use this method only in emergency situations. For normal
engine shut down follow the procedure given in Stop the
Rider and Engine.
NOTE: If th) )ngin) (o)s not start aft)r r)p)at)( att)mpts,
contact an authorized dealer.

Driving the Tractor

1. Sit in the seat and adjust the seat so that you can com-
fortably reach all the controls and see the dashboard
display.
2. Engage the parking brake.
3. Make sure the PTO switch is disengaged.
4. Start the engine (see Starting the Engine).
5. Disengage the parking brake and release the brake
pedal.
6. Depress the forward ground speed control pedal to
travel forward. Release the pedal to stop. Note that the
further down the pedal is depressed the faster the trac-
tor will travel.
7. Stop the tractor by releasing the ground speed control
pedals, setting the parking brake, and stopping the en-
gine (see Stopping the Tractor and Engine).
21
