Installation
Before installation, check strength and horizontality of the base so that abnormal sound does not generate.
According to the dimensions and clearances, fi x the base fi rmly with the anchor bolts (Anchor bolt, nut: M10 x 2 pairs). If
the outdoor unit is installed in a very windy place, protect the fan with a wind protection screen and check that it works
correctly.
Required tools for installation
- Philips screw driver
- Cutter drill (65 mm)
- Spanner
- Pipe cutter
- Cutter
- Reamer
- Gas leak detector
- Meter
- Thermometer
Filed supplied material
Refrigerant pipes; Pipe insulating material (polyethylene foam, 6 mm thick), Putty, PVC tapes.
Knockout procedure
The indoor/outdoor connecting pipes can be connected to
4 directions (See fi g. 4)
Take off the knockout part of the pipe cover in which pipes
or wires pass through the base plate.
Do not remove the pipe cover from the cabinet so that the
knockout hole can be easily punched.
How to remove the front panel
1. Remove screws of the front panel (See fi g. 6).
2. Pull the front panel downward.
6 38AW-
128H50_38AW copia.indd 6 128H50_38AW copia.indd 6
- Volt-ohm-milliammeter
- Electro circuit tester
- Hexagonal wrench
- Flare tool
- Pipe bender
- Water level
- Metal saw
- Hammer
To knock out, punch the 3 connected parts with a
screwdriver and remove the pipe cover by hand
(See fi g. 5).
After marking the knockout hole, remove the burr and
mount the attached protective bush and guard material for
pass-through part in order to protect pipes and wires.
(Fig. 4 - 7)
(Fig. 4, 5)
(Fig. 6)
