5. Follow the instructions below for adding the contents of the cleaning agent bag(s) to the cleaning
agent receptacle.
A. Dry hands before opening the cleaning agent bag.
B. Open the cleaning agent bag as shown.
C. Empty all the contents of the specified number of cleaning agent bags into the cleaning agent
receptacle (see Table 1).
D. Avoid handling the contents of the cleaning agent bag.
A
B
After adding all the contents of the cleaning agent bag(s), properly dispose of the bag(s) and close
the system lid.
6. Select one of the three cycle lengths by pressing the cycle length button.
Each press of the cycle length button increases from a short cycle to a medium cycle or to a long cycle
length. Pressing the cycle length button once more returns to the short cycle length.
Table 2 should also be used as a general guideline for selecting cycle lengths for most models.There
are some factors that cause the support removal process to take longer such as model geometry,
small support filled crevices, small blind holes, or low water temperature coming into the system.
Table 2 Cycle Length Settings
Combined Build Times
≤ 4 hrs.
4 to 12 hrs.
> 12 hrs.
NOTE: When placing more than one model in the same cleaning cycle, use the combined build
times of all the models to determine the correct cycle length setting. Combined build time means
the sum of the individual build times of each model put into the model basket.
C
Cycle Selection
Short
Medium
Long
6
D
Approximate Cycle Times
3 hrs.
6 hrs.
12 hrs.
