Delicate and flat models should be placed in the model bag on the model basket lid. When using the
model bag, always select the lower lid position and do not add other models to the model basket.
• Delicate models have features with a cross sectional areas under 19 sq. mm (0.03 sq. in.).
• Flat models have large flat areas that are greater than 64 mm x 64 mm (2.5 in. x 2.5 in.) and
less than 3 mm (1/8 in.) thick.
3. Based on the model lid position, select either a full (upper lid position) or half (lower lid position)
cleaning tank level by pressing the cleaning tank level button. A full cleaning tank level is approxi-
mately 15.14 L (4 gals.) and a half cleaning tank level is approximately 7.57 L (2 gals).
4. Select the number of cleaning agent bag(s) to be used based on Table 1 below.
Table 1 Cleaning Tank Level and Cleaning Agent Bags
Cleaning Tank Level
Half cleaning tank level
Full cleaning tank level
NOTE: Do not use more than the specified amount of cleaning agent bags. Doing so will exceed
pH levels for wastewater disposal.
Cleaning Agent Bag
1 cleaning agent bag
2 cleaning agent bags
