Troubleshooting

Symptom / Error
An asterisk (*) is
o
displayed next to the
Device type in the
device manager
screen indicating that
the device is not
communicating.
In the Communication
o
status screen, the
number of detected
devices does not
match the number of
communicating
devices.
The device is powered
o
on but the green LED
is OFF
The device is powered on
and the green LED is ON
All the devices are not
communicating
SolarEdge-Immersion Heater Controller Installation Guide MAN-01-00279-1.3
Possible cause
Try to solve using these options. If problem is not solved,
proceed with the next option:
The device
o
is not associated with
the inverter
o
o
o
The device is
Associated with the
inverter but is not
communicating.
No ZigBee error is
o
displayed on the
inverter LCD - The
o
inverter has not
detected the installed
o
ZigBee module.
Immersion Heater Controller Installation Guide
Troubleshooting
Turn the device OFF and ON. Recheck
communication.
Reset the device by pressing the button for more than
10 seconds and then repeat the association process.
Reconfiguration is not required.
From the Device Manager screen select Remove
Device and repeat the discovery process.
Reconfiguration is required in this case.
Contact SolarEdge support.
Turn OFF the AC to the inverter
Check that the ZigBee module is inserted correctly
inside the inverter.
Turn ON the AC to the inverter
11
