Button Functionality

Button Functionality
The following table describes the device button functions depending on the network association state:
Network state
No ZigBee association with
the inverter
ZigBee associated with the
inverter
LED Indications
The device has three LEDs that provide information about the device operation status:
LED color
ON -The device is associated with the inverter
Flashing slow - Reset
Green
Flashing fast - Association in process
OFF - The device is not associated
ON - The device is delivering the maximum power to the load
Yellow OFF - The device is not delivering any power to the load
Flashing - The device is delivering intermediate power
ON - The device is in ontrolled locally. "Boost" mode is active,delivering the maximum
power to the load for 1 hour
Red
OFF - The device is controlled remotely. "Boost" mode is inactive.
When the device is initially switched on all its LEDs remain ON for two seconds, then they flash quickly for
two seconds.
10
SolarEdge Immersion Heater Controller Installation Guide MAN-01-00279-1.3
Pressing duration
Any
Up to 3 seconds (short press)
More than 3 seconds (long
press)
Result
Attempting to associate with the network
Switching the device to "Boost mode", in which the
device delivers the maximum available power to
the load, overriding any programmed mode like
Schedule or Smart Save. The device returns to its
previous operating mode after an hour, or if the
button is short-pressed again within an hour.
During this mode the red LED is on.
Disconnecting from the network, however not
removing the device from the list of devices. An
astrisk (*) next to the device name in the device
manager indicates it is not communicating.
The green LED turns off.
Re-associating the device will load the previous
configuration so re-configure is not required.
Indication
