English
PRECAUTIONS ON USING DRILL
1. Wear ear protectors with impact drills.
Exposure to noise can cause hearing loss.
2. Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
3. Never wear gloves during operation.
Gloves are sometimes caught by rotating parts,
resulting in serious injury. Do not use gloves during
operation.

SPECIFICATIONS

Voltage (by areas)*
Power input
No load speed
Steel
Capacity
Wood
Weight (without cord)
*Be sure to check the nameplate on product as it is subject to change by areas.
STANDARD ACCESSORIES
(1) Chuck wrench ............................................................ 1
(2) Side handle ................................................................ 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
(1) Handle joint
(2) Depth Stopper
Optional accessories are subject to change without notice.
APPLICATIONS
Drilling in metal, lumber and plastics.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF position.
If the plug is connected to a receptacle while the
power switch is in the ON position, the power tool
will start operating immediately, inviting serious
accident.
3. Extension cord
When the work area is removed from the power
source. Use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Confirm the direction of bit rotation
The drill bit rotates clockwise (when viewed from
the rear) when the lever of the reversing switch is
set to the "R" position, and rotates in the reverse
direction when the lever of the reversing switch is
set to the "L" position.
4
4. Install the side handle and hold the tool firmly with
both hands.
One-hand operation is very dangerous. Always install
the side handle and hold the tool with both hands.
Holding the tool insufficiently can result in serious
damage during operation.
5. Before drilling into walls ceilings or floors, ensure
that there are no concealed power cables inside.
(110V, 115V, 120V, 127V, 220V, 230V, 240V)
720 W*
550 min
13 mm
40 mm
3 kg
5. Fitting the drill bit
Fit the drill bit into the chuck and use the chuck
key to secure it, tightening the chuck by each of
the three holes in turn.
6. Selecting the appropriate drill bit
When boring metal or plastic
Use ordinary metalworking drill bits.
Sizes range from a minimum of 1.2 mm to chuck
maximum capacity.
When boring wood
Use ordinary woodworking drill bits.
However, when drilling 6.5 mm or smaller holes,
use a metalworking drill bit.
7. Installing spade handle
The spade handle can be installed on the back of
the drill. Insert the bolt through the hole in the
spade handle, locate the spade handle in the desired
position and tighten the bolt firmly.
8. Installing the side handle
The side handle screws into the housing on either
side of the gear cover. For safe operation, use of
the side handle is necessary. Especially in heavy
duty drilling, use handle joint and side handle.
9. Installing the depth stopper (optional accessory)
The depth stopper which is useful for adjusting the
drilling depth is available. Install the depth stopper
to the gear cover using the side handle or set screw.
PRACTICAL HANDLING PROCEDURES
1. Pressure
Drilling will NOT be accelerated by placing heavy
pressure on the drill. Such action will only result
in a damaged drill bit, decreased drilling efficiency,
and/or shortened service life of the drill.
2. Using a large diameter drill bit
The larger the drill bit diameter, the larger the
reactive force on your arm. Be careful not to lose
control of the drill because of this reactive force.
To maintain firm control, establish a good foothold,
