Marquette Hellige GmbH
SpO
2
* saturation: 0 to 100 %, in 1-% increments
* frequency: 0 to 250 BPM, in 1-BPM increments
* alarm limit: off, 15 to 100 %
* display of plethysmogram
* C-LOCK ECG synchronization
* integration time: 4, 8 and 12 seconds
* measuring accuracy:
Pacemaker
* operating modes: demand, fixed-rate, overpace
* pacing rate: 30 to 150 BPM (overpace up to 300
BPM)
* pacing current:
Ohms), voltage up to 120 V
* pulse width (demand, fixed-rate): 40 ms
(overpace):
* pulse shape: monophase square-wave pulse
70 to 100% ±2 digits
50 to 69% ±3 digits
pulse display 1.2% or
±1 BPM
0 to 200 mA (for 500
20 ms
CardioServ V. 3
Power
from the power line
* 95 V to 240 V, 49 Hz to 65 Hz
* from a 12-Volt power source of the emergency
vehicle
* from exchangeable, rechargeable NiCd batteries
* rated voltage 12 V
* rated capacity 1.4 Ah
* battery is charged while inserted in the device
* charging time for depleted battery approx. 16
hours
* operating time with a fully charged battery
approx. 35 defibrillation shocks of 360 joules
each (into 50 ohms) or 2 hours of monitor
operation (1.2 hours with pacemaker and SpO
measuring system)
Operational readiness
4 s after power up (incl. automatic selftest)

Operating position

any
Page 41
