MOVE THE MICROPHONE ASSEMBLY
(DUAL HEADSET ONLY)
The dual earcup headset has a reversible microphone assembly that can be worn on
the left or right side of the headset.
1. Using a Phillips screwdriver (not provided), loosen the two screws on the
microphone assembly base on the bottom of the earcup.
NOTE: Rotate the microphone up towards the headband for additional space to
loosen the screws.
2. Pull the microphone assembly down to remove from the earcup.
3. On the other earcup, loosen the two screws on the terminator cover.
4. Pull the terminator cover down to remove from the earcup.
M I CR OP HO N E MI CR OP HO N E
Microphone
assembly
Terminator cover
|
