Service of manifold
•
•
•
•
•

Auto shut-off

Approximately 10 minutes after the last measurement or keypress the
DIGIMON shuts off itself.
Disposal of manifold
Dispose of the manifold according to the rules and regulations of the coun-
try of use.
Spare parts for DIGIMON manifold
Description
Handwheel red
Handwheel blue
Complete valve set
Piston incl. gaskets
Sight glass set
External temperature sensor DIGIMON-EXTERNAL-
Battery compartment cover
Tool for sight glass
Tool for valve core
Plastic case
Refrigeration
Service Products
and Components
REFCO Manufacturing Ltd.
Industriestrasse 11
CH-6285 Hitzkirch (Switzerland)
The charging hoses must be checked and free of oil residue before each
use. A visible inspection is also necessary to ensure that the hoses and
the connection are undamaged and tight.
The seals and gaskets of the manifold are parts of use and must be re-
placed from time to time. The manifold is to be tested regularly to ensure
the valves are still tight.
If a manifold shows to be leaking the pistons of the valves can easily
be replaced and are available as a spare part. Please refer to the manifold
accessory section of the REFCO catalog.
If the sight glass is leaking a replacement kit is available. To change the
sight glass a special tool is necessary (M4-6-11-T) which is available
from REFCO. Replace and tighten the new sight glass carefully in order
to prevent damage to the glass.
After installing spare parts to the manifold it is necessary to test the
manifold for leaks before the next use.
Designation
M2-7-SET-R
M2-7-SET-B
M2-10-95-R/10
M4-6-04-PA/10
M4-6-11
SENSOR
DIGIMON-BATTERY-
COVER
M4-6-11-T
A-32000
DIGIMON-CASE
Telefon +41 41 919 72 82
Telefax +41 41 919 72 83
Info@refco.ch www.refco.ch
Part number
4677826
4677834
4662607
4662624
4493169
4677647
4676374
4493169
9880890
4676497
