Quick Reference guide

Figure 1
① the electrical information
regarding your electric fireplace can
7"
be found on the rating label located
(17.8 cm)
on the front of the unit, behind the
glass.
Before installation, please record your
fireplace's serial number below for
future reference.
16" 18"
② If you have any technical
(40.6 cm) (45.7 cm)
questions or concerns regarding the
operation of your electric fireplace,
or require service contact customer
service.
③ For dimensions of your fireplace,
13
3 "
16
refer to Figure 1.
(9.7 cm)
1
48 " (123 cm)
2
46" (116 cm)
3" (7.6 cm)
5
50 " (128 cm)
16
1
19
2
(49.5 cm)
