Power trim function (around 0° - 15°, slow tilt motion):
Can be operated when driving the boat. Allows fine tuning between the boat's hull and
the propeller's angle in the water. Allows optimization of driving behaviour and
efficiency.
Power tilt function (around 15° - 80°, fast tilt motion):
To be used in stationary position of the boat to tilt the outboard out of the water. Protects
underwater components of the motor against additional wear, aging, algae growth, etc.

4.4 On-board computer and touchscreen display

1
3
8 9
6 Distance to "Home" (if "Home" has
been stored under "Settings")
Current distance covered (is set to
7
zero when motor is switched off)
Selection of main screen (selected)
8
Selection of Navigation screen
46 9
• Before tilting the motor down: Make sure that the tilt lock on the
transom bracket does not restrict the shaft from being tilted down.
• Tilting up of the motor drains cooling circuit of the outboard.
Please always put the motor into tilted position to ensure entire drai-
nage. This also prevents wear and helps to extend service life of the
outboard system!
5
6
7
10 11
2
4
12 13 14
Selection of Motor Data screen
10
Selection of Battery Data screen
11
Selection of Charger Data screen
12
Selection of Settings
13
Selection of Error Display
14
Main screen
Input power
1
Speed over ground
2
Battery charge status
3
Power limitation, desi-
4
gned for slow moving
within limited areas like
harbours (deactivation
only in neutral position)
Remaining range at
5
current speed (if no
GPS signal is available,
remaining range is not
displayed)
