VIPA System MICRO
Write n Bits 0Fh
Kommandotelegramm
Slave-
Funktions-
Adresse
Code
1Byte
1Byte
Antworttelegramm
Slave-Adresse
1Byte
Write n Words 10h
Kommandotelegramm
Slave-
Funktions-
Adresse
Code
1Byte
1Byte
Antworttelegramm
Slave-Adresse
1Byte
HB400 | CPU | M13-CCF0000 | de | 19-30
Code 0Fh: n Bit schreiben in Master-Ausgabe-Bereich 0x
Bitte beachten Sie, dass die Anzahl der Bits zusätzlich in Byte anzugeben sind.
Adresse 1.
Anzahl der
Bit
Bits
1Wort
1Wort
Funktions-Code
1Byte
Code 10h: n Worte schreiben in Master-Ausgabe-Bereich
Adresse 1.
Anzahl der
Wort
Worte
1Wort
1Wort
Funktions-Code
1Byte
Anzahl der
Daten 1.
Bytes
Byte
1Byte
1Byte
Adresse 1. Bit
1Wort
Anzahl der
Daten 1.
Bytes
Wort
1Byte
1Wort
Adresse 1. Wort
Anzahl der Worte
1Wort
Optional: PtP-Kommunikation
Modbus - Funktionscodes
Daten 2.
...
Byte
1Byte
1Byte
max. 250Byte
Anzahl der Bits
1Wort
Daten 2.
...
Wort
1Wort
1Wort
max. 125Worte
1Wort
Prüfsumme
CRC/LRC
1Wort
Prüfsumme
CRC/LRC
1Wort
Prüfsumme
CRC/LRC
1Wort
Prüfsumme
CRC/LRC
1Wort
265
