Digital Projection HL12000Dsx+ Bedienungsanleitung Seite 13

MM-RGB
(Built-in)
MM-DVI
(Optional Board)
MM-SDI
(Optional Board)
Input / Output Terminal
Input Slot
MM-VIDEO
(Built in)
MM-RGB
(Built in)
MM-DVI
(Optional Board)
MM-SDI
(Optional Board)
USB Port
LAN Port
Remote Control
PC Control
PC Card
Ex. Control
Power Requirement
Power Consumption
Input Current
Dimensions
Net Weight
R,G,B,H,V R,G,B
Y
Cr,Cb
(Component accepts HDTV and >31kHz interlaced and progressive
inc 1080i/60, 1080i50, 24sF, 25p, 24p 23.98p/sF, 720p/60 but not 60p,
RGsB, RGBS, RGBHV accepts HD progressive and progressive computer)
H/V Sync
Composite Sync : 1kohms / 75ohms (Selectable)
Sync on Green
Digital RGB Single Link : Pixel Clock Frequency 165MHz Max
Dual Link
SDI SDTV
HDTV
(includes
4 slots (One board each for the VIDEO board and analog RGB input board are standard equipment;
2 slots are for expansion.)
Video Input
Input
Input
Analog RGB Input
Audio Input
Digital RGB Input
Audio Input
SDI Input
SDI Output
A Type 1, B Type 1
RJ-45 1
In Stereo Mini Jack 1, XLR Connector 1
Out Stereo Mini Jack 1
In D-Sub 9pin 1
Out D-Sub 9pin
TypeII 1
Mini D-Sub15pin 1
200 - 240VAC, 50 / 60Hz
HL12000Dsx+ / HL8000Dsx+ : 2.8KW
HL12000HD / HL10000HD : 3.0KW
HL12000Dsx+ / HL8000Dsx+ : 14A
HL12000HD / HL10000HD : 15A
HL 12000Dsx+ / 12000HD :
HL 8000Dsx+ / 10000HD :
HL12000Dsx+ :
HL8000Dsx+ :
HL12000HD :
HL10000HD :
: 75chms 0.7Vp-p positive polarity
: 75ohms 1.0Vp-p positive polarity (with Sync)
: 75ohms +/-0.35Vp-p positive polarity
: 1k ohms / 75ohms (Selectable)
0.7 – 4.0Vp-p / TTL positive / negative polarity
Duty N/A
0.7 - 4.0Vp-p / TTL Positive / negative polarity
Duty N/A
: 75ohms 1.0Vp-p (including sync signal component of 0.3Vp-p)
: Pixel Clock Frequency 202.5MHz Max
: SMPTE 259M Level-C
: SMPTE 292M (include 24sF,24p)
1080i/60, 1080i50, 24sF, 25p, 24p 23.98p/sF, 720p/60 but not 60p)
BNC 1 (Composite Video)
BNC 2 (S-Video)
BNC 3 (DVD Component)
BNC 5 (shared with the component input connectors)
RCA (L/MONO,R) 1 (No Function)
DVI-D 1
Stereo Mini Jack 1 (No Function)
BNC 2
BNC 1
*3
1
27.2" (W) 40.1" (D) 20.4" (H)
690mm (W) 1018mm (D) 547mm (H)
26.4" (W) 36.5" (D) 16.8" (H)
670mm (W) 926mm (D) 425mm (H)
185.2lbs (84kg) (without lens)
150lbs (68kg) (without lens)
194.7lbs (88.3kg) (without lens)
164lbs ( 74.6kg) (without lens)
13
3. Specifications
