adjustment is located on the underside of the TLR-2
pointed down range a clockwise turn of the adjustment screw will move the laser down (POI up).
A counter-clockwise turn on the adjustment screw will move the laser up (POI down). Move the laser dot in
the direction that the shots are hitting the target (example: If the bullets are striking low and right, move
the laser dot down and right to coincide with the bullet strike).
NOTE: When making large adjustments there may be an interaction that causes the laser to move diago-
nally or bind. It may become necessary to rotate the opposing adjustment screw counterclockwise to allow
the laser cartridge to move to the desired position.
Maintenance
The TLR rail clamp tensioning bolt requires an application of high quality gun oil to keep it rust free. Use a soft
cloth and mild detergent to clean the glass LED lens and keep it free of dirt and grime. The laser aperture on
the TLR-2
models can be cleaned with a Q-tip (or similar item) and mild detergent.
®
NOTE: Always avoid aggressive cleaning solutions as they may damage the TLR.
Straight or Coiled
Cord Available
TLR Contour Remote Switch
(Contour remote not recommended for use with the TLR-2 HL
model laser cartridge. With the TLR-2
®
Accessories
TLR Remote Switch
(TLR-1 HPL
shown)
®
(TLR-1
Shown)
®
model
®
G)
®
