2.2 REAR PANEL CONNECTIONS
EA470 4-CHANNEL AMPLIFIER
13
SPEAKER OUTPUT TERMINALS 1/2-CH and 3/4-CH
Output terminals to connect the speakers in stereo or bridged mode to the amplifier.
14
POWER INPUT TERMINAL "GND"
Terminal to connect the amplifier to the negative or ground pole of the car battery.
15
REMOTE INPUT TERMINAL "REM"
Terminal to connect the amplifier to the automatic (remote) turn-on / turn-off lead of
the head unit.
16
POWER INPUT TERMINAL "+12 V"
Terminal to connect the amplifier to the positive +12V pole of the car battery.
REAR PANEL
EA470
1a/1b
4
5
13
2a/2b
6
7
8
13
9
10
12
14
15
16
11
