Remedy Of Faults; Maintenance And Cleaning - Oase Water Quintet Creative Gebrauchsanleitung

The manual transmitter as part of our scope of delivery is taught in for the 12 V control box. The 12 V control box has
to be adapted to every further manual transmitter.
Teaching-in manual transmitter (J):
The receiver is equipped with a teach-in button (24) to adapt the 12 V control box to the transmission signal of the
manual transmitter.
• Insert a pin (23) into the opening for the teach-in button (24) until you feel a resistance. Keep pressing in the pin (23)
until this resistance is overcome. The teach-in button (24) is then activated.
• Actuate the teach-in button (24) using the pin (23) for approx. 1 sec.
• Then press any button of the manual transmitter for at least 1 sec.
Deleting the manual transmitter (J):
• Actuate the teach-in button (24) using a pin (23) for at least 5 sec.
This deletes all manual transmitters stored in the receiver.
Note: A maximum of 10 manual transmitters can be set to the receiver. The manual transmitter has a maximum range
of 80 m. Obstacles between transmitter and receiver, a low battery in the manual transmitter, or electro-magnetic radia-
tion of electrical equipment will impair the range.
Aligning the water fountain (K):
• Swivel the LED light nozzle (25) to align the water fountain.

Remedy of faults

Malfunction
Pumps do not start
Unit does not respond to manual transmitter
Insufficient fountain height
Unit switches off after a brief running time (ap-
prox. 10 s)

Maintenance and cleaning

W A R N I N G
Possible death or severe injury from hazardous electrical voltage!
• Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
• Isolate the device (disconnect from the power supply) before carrying out any work on it.
Cleaning the unit (L, M, N):
• To open the unit loosen the nozzle holders (9) by slightly turning. Unscrew the LED light nozzles (10) and, if fitted, the
extension tubes (6) (see Fig. D).
• Laterally slide the respective pump (26) out of the engagement holder of the filter basket (27).
• Slightly turn the pump cover to disengage (28), then remove the impeller (29).
• Clean all components under running water using a brush.
Reassembling the unit:
Reassemble the unit in the reverse order (L, M, N).
Note: Push the pump housing into the filter basket until it tangibly engages.
Cause
No mains voltage
Manual transmitter not taught in
Impeller blocked or soiled
Pump strainer casing soiled
Nozzles soiled
Water temperature too high
Pumps run dry
Remedy
Check mains voltage
Check supply lines
Teach-in manual transmitter
Clean impeller
Clean strainer casing
Clean nozzles
Note maximum water temperature of + 35°C.
For switching on again, pull the power plug and
reinsert in the socket.
Check water level and, if necessary, top up the
water. For switching on again, pull the power
plug and reinsert in the socket.
