Commissioning/start-up
The unit switches on automatically when the power connection is established. If it does not switch on, the protection
device may have tripped. (→ Remedy of faults)
W A R N I N G
The propeller rotates very fast. Severe injuries to the limbs possible.
• Only switch on the unit with the protection grid fitted.
Switching on the unit
 J, K
• Establish the power connection.

Switching off the unit

 J, K
• Disconnect from the power supply.
Cleaning
W A R N I N G
Possible death or severe injury from hazardous electrical voltage!
• Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
• Isolate the device (disconnect from the power supply) before carrying out any work on it.
• If necessary, clean the unit with clear water using a soft brush.

Remedy of faults

W A R N I N G
The propeller rotates very fast. Severe injuries to the limbs possible.
• Disconnect the power plug before carrying out any work on the unit.
Malfunction
The unit does not switch on
Pump switches off after a short running period.
Incorrect propeller rotational direction of the
400 V unit
Irregular spray pattern effect, loud flow noise
Cause
No mains voltage
The protection device has tripped.
Pump overload
• Excessively soiled water
• Water temperature too high
• Filter basket soiled
• Propeller seized up due to soiling
• Motor defective
Mains phases in the CEE socket reversed
Filter basket soiled
Remedy
Check the mains voltage.
Clean, check supply lines
AirFlo 230 V, 1.5 kW / 400 V, 1.5 kW:
(→ Switching on the automatic cut-out device
AirFlo 230 V, 1.5 kW / 400 V, 1.5 kW)
AirFlo 400 V, 4.0 kW:
(→ Switching on the motor (overload) protec-
tion switch AirFlo 400 V, 4.0 kW)
Clean filter basket
Only operate the unit at the water temperature
specified in the technical data.
Clean the filter basket under running water us-
ing a brush.
Remove soiling.
Contact OASE
Ensure that the propeller rotates counter-clock-
wise (CCW). Connect the mains phases in the
CEE socket to comply with the rotational direc-
tion.
Clean filter basket
