Contact control
Before a sequence or a single program is executed, the device checks whether
the required electrical contact is made. If the contact is not good enough, you will
hear a beep every 3 seconds. By pressing the OK-button, the frequency program
can be executed anyway. However no effect will occur.
If the required contact is made, the display shows for a short time the resistance
in kilo-Ohms and then the device automatically begins executing the frequency
program.
During the execution of frequency programs
• In the headline the sequence name and the name of the current single
program are shown in turns.
• Below the remaining execution time is counted down
(minutes: seconds).
• Below the intensity is displayed.
• For frequency programs with constant current control, the actual
voltage is displayed on the left side. On the right side the chosen
intensity is displayed in milliamps (1/1000 amps). (see left figure)
• For frequency programs without current control, only the voltage in
volts is displayed. (see right figure)

Operating options

Pressing the START-button will interrupt the program.
Repressing the START-button will play the program from
the point of interruption.
The intensity can be adjusted using the arrow keys up
and down.
Pressing the EXIT-button will quit the current application.
