Menu structure

Mode
DMX mode
Preset colors
Internal program
Color mix
Stand-alone mode
Preset colors
In the C mode the device will constantly emit one of 7 preset colors.
1 Press the MODE button so many times until C is indicated in the display. Confirm with the ENTER
button.
2
Use the buttons UP and DOWN to adjust the desired color (C01-C07). Confirm with the ENTER button.
Internal program
When the display shows P, you can select the desired internal program.
1 Press the MODE button so many times until P is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to adjust the desired color (P01-P04). Confirm with the ENTER button.
Color mix
You can select the dimmer itensity of the LED colors (from 0 to 100 % 1-255]).
Please see the table
Display
Addr d001-512
5CH (default setting)
CH
3CH
C01
C02
C03
C C04
C05
C06
C07
P01
P02
P
P03
P04
r 0-255
G
0-255
b
0-255
19/24
Function
Setting the DMX Start Address
Setting DMX Mode
Setting DMX Mode
Red
Yellow
Green
Cyan
Blue
Magenta
White
Endless loop in 7 colors,
change every 3 seconds
Endless loop in 7 colors,
fade every 3 seconds
Endless loop in 3 colors,
change every 3 seconds
Endless loop in 3 colors,
fade every 3 seconds
Red 0-100%
Green 0-100%
Blue 0-100%
