3 FEATURES & SPECIFICATIONS
Features
• A 50W white LED lamp
• 50000 hours life span and low power consumption
• 8/16 bit smooth and precise resolution for PAN/TILT movement
• 360°/540°/630° PAN and 90°/180°/270° TILT movement
• Scan position memory, auto reposition after unexpected movement
• Specific optic system with 11.9° projection angle
• Improved optics and flat beam field
• 1 rotatable gobo wheel with 6 rotatable and interchangeable gobos plus open with
speed adjustable, stream effect, dithering effect and rotatable clockwise or
anticlockwise
• Gobo size 21.8mm (external dimensions)/14.5mm (inner dimensions)
• 1 color wheel with 7 colors plus open
• Variable direction rainbow effect with speed adjustable
• 2 meter to infinite electric focus
• 1 3-facet prism with variable speed and direction
• 0-100% linear LED dimmer
• 25T/sec high speed LED shutter/strobe effect with variable speed
• Preset variable/random strobe and dimming pulse effect
• 11/13 DMX channels USITT DMX-512
• DMX512, master-slave, and sound activated controllable or auto operation (7
built-in programs)
• DMX recorder and edit function integrated
• Red background LED display
• Powercon connector IN
• 3-pin XLR connectors IN/OUT
• Fan cooling system
• Constant temperature readout and management function
• 45°C max ambient temperature
• IP20 protection rating
• 55dB at 3'dB rating
• 1*hanging kit
Rotating gobos Colors
Rose
Cyan
Red Green
Carmine
Blue Orange Yellow White
E 04
Für Anlagen mit sehr langen DMX-Kabelwegen oder hohen
elektrischen Störeinflüssen, wie zum Beispiel in einer
Diskothek, ist es empfehlenswert, eine DMX-Terminator zu
verwenden. Der DMX-Abschlusswiderstand wird in einem
XLR-Stecker als 120 Ω Widerstand zwischen Pin 2 und 3
ausgeführt der in die letzte Ausgangsbuchse der DMX-Linie
gesteckt wird.
8 Menüstruktur
MODE ADDR VALU
SLAV
AUTO IP1~8
SOUN IP1~8
SET MIC M-XX
LODA ON/OFF
VER V-1.0~V-9.9
CALI CH1
CH2
CH3
DMX MOD1
MOD2
REST ON/OFF
SIGL S1
S2
S3
TEMP TXXX
DEGR PAN 630/540/360
TILT 270/180/90
Up
Mode
120 Ω
3
1 2
A001~AXXX (AXXX) DMX address setting
ON/OFF (SLAV) Slave
ALON (AU-A) Alone setting
MAST (AU-M) Master setting
ALON (SO-A) Alone setting
MAST (SO-M) Master setting
Mic sensitivity
Data reload
Software version
0--255 Color calibration
0--255 Gobo calibration
0--255 Focus calibration
16B mode
8B Mode
Reset
Wired mode
Wireless Mode
Wireless IN and wired OUT
Termperature reading
PAN angle options
TILT angle options
LED DISPLAY
Down
Enter
MIC
D 09
PIN3
PIN2
