Product Specifications; Technical Specification - Expolite TOUR-FLASH MINI Bedienungsanleitung

14
1.0

PRODUCT SPECIFICATIONS

1.1

TECHNICAL SPECIFICATION

voltage
power consumption
strobe/pixel/flood
DMX mode
LEDs
segment control
beam angle
operation temperature
housing
protection class
width
depth
height
weight
1.2
PEAK AND CONTINUOUS POWER
Peakpower of the fixture used as strobe is higher then the con-
tinuous power in pixel or flood mode. In pixel or flood mode, the
forced cooling is limited.
LED´s peakpower in strobemode: 300 W
LED´s continuouspower in pixel/flood: 150 W
Dynamic powerreduction: >55°C
Protect: >70°C
110-240VAC 50/60Hz
300 Watt / 150 Watt
1/3/4/6/7/16
324 x SMD5050 5600K
9-fach
120°
0° - 40°C
Aluminium
IP20
360 mm
110 mm
180 mm
2.80 kg
