Specification - Eldom Ride DA34 Gebrauchsanleitung

DESCRIPTION
1. Indicator light
2. Folded grip
3. Steam shot button
4. Water inlet
5. Water tank
6. Thermostat knob
7. evaporation switch
8. Voltage switch
9. Body
10. Sole
11. Base
12. grip lock release

SPECIFICATION

power: 1000 W
Power supply: 230/115V ~ 50/60Hz
USE
Before the first use, remove (unpeel) the factory cover of the sole (10), unroll the power cord fully and set the
proper power supply voltage with the switch (8).
During the initial use of the device, harmless odour may be emitted from it. This is short-lasting and has no effect
on the operation.
POWER SUPPLY VOLTAGE SWITCH
The iron can be operated with either of two power supply voltage systems: 115 V and
230 V (fig. 2)
Before connecting the device to the mains, make sure that the switch (8) is in the
position indicating the power supply voltage of your network. The position of the
switch may be changed with a flat-ended screwdriver.
CAUTION
The switch position must not be changed when the device is connected to the mains!
FOLDED GRIP
The iron is fitted with the folded grip (2) and the sole (10). This solution facilitates storage of the device, e.g.
during travels. To prepare the iron for use, hold it by the body (9) and pull the grip upwards to hear the click
sound. This will release the sole (10) from the body (9). The grip may be folded after pressing the button (12) in
the base of the device (11) (fot 1).
CAUTION
The grip may be folded and unfolded only when the iron is disconnected from the mains and is not hot
(is cold).
IRONING WITHOUT STEAM
Before connecting the device to the mains, make sure that the switch (8) is in the position indicating the power
supply voltage of your network.
Set the thermostat knob (6) in the position "off", and the steam switch (7) in the position "
the grip (2) upwards and place the iron on the base (11).
Connected the device to the mains.
OPERATING INSTRUCTION
TRAVeL IRON DA34
3 4
2
6
1
10
EN
5 11 12
7
8
9
fig. 1
fig. 2
" (no steam). Pull
EN
•
9
