Connector pinout

Pin Function
1 Auxiliary DC Power Output
2 GND
3 Digital Input 1
4 Digital Input 2
5 Digital Input 3
6 Digital Input 4
7 Transistor Output
8 Transistor Output
9 Transistor Output
10 Transistor Output
11 RS-485 - A (non-inverting)
12 RS-485 - B (inverting)
To connect input/output devices to the I/O terminal connector:
1. Referring to the table above, loosen the corresponding screw on top of the pin on the green
connector block.
2. Push the cable into the connector block and secure it by fastening the screw.
3. Once all devices are connected, push the connector block into the terminal connector on the
rear panel of the AXIS Video Server Rack.
For compatible replacement connectors, contact http://www.phoenixcontact.com, quoting:
MC1.5/12-ST-3.81 (art no 1803675).
Axis Rack Mounted Video Server Solution
Description
This pin can be used to power auxiliary equipment, max 100mA
Connect to GND to activate or leave floating (or unconnected) to
deactivate.
With a maximum load of 100mA and maximum voltage of 24V DC, this
output has an open-collector NPN transistor with the emitter connected to
pin 2 (GND). If it is to be used with an external relay, a diode must be
connected in parallel with the load for protection against any voltage
transients.
A half-duplex RS-485 interface for controlling auxiliary equipment,
e g. PTZ devices.
