Part Location; Anatomy; Bottom View - Vileda Relax Betriebsanleitung

1
1. Main Unit
2. Battery Charger
3. Rechargeable Battery Pack (installed)
4. Filter Mesh (extra)
5. Side Brush (extra)
6. Maintenance Brush
Top View
1) Handle

Bottom View

4) Rechargeable battery
5) Cliff sensors
6) Side brush
7) Power switch

Part location

2 3

Anatomy

4 5
2) Program buttons
3) Removable dust bin
8) Main rotating brush
10) Vaccum inlet cover
9) Filter
11) Battery charger socket
G
6
5
