T R A N S L AT I O N O F T H E O R I G I N A L
ASSEMBLY INSTRUCTIONS
Contents

About this handbook

Unpacking the lawn tractor
Lawn tractor assembly
Mounting the rear wheels
Mounting the steering wheel
Mounting the operator's seat
Hooking in the fill-level signal
transmitter of the grass catcher
Assembling grass catchers
Installing the starter battery
ABOUT THIS HANDBOOK
- Before assembling the lawn tractor,
r e a d t h r o u g h t h e s e a s s e m b l y
instructions carefully and perform all of
the assembly work conscientiously.
Please ask a dealer or the manufacturer
if you have any questions or doubts
about assembly.
- Comply with the lawn trac tor 's
i n s t r u c t i o n s f o r u s e r e g a r d i n g
operation of the lawn tractor.
- Keep the assembly instructions to refer
to during use of the product, and pass
them on to subsequent users.
- The lawn tractors are supplied with
different levels of equipment. Please
note that the illustrations may differ
somewhat from the original. Please
contact a specialist workshop or the
m a n u f a c t u re r i f yo u e n co u nt e r
d i f f i c u l t i e s i n f o l l o w i n g t h e
descriptions.
Explanation of symbols
WARNING!
Observe this danger note in order to
avoid serious personal injuries.
CAUTION!
11
Following these warning instructions
can help to avoid personal injuries and/
11
or damage to property.
11
Special instruc tions for ease of
understanding and regarding handling.
12
UNPACKING THE LAWN TRACTOR
12
The lawn tractor is supplied on a sturdy
wooden pallet.
12
Place the pallet on level ground in order to
unpack the tractor.
12
1. Remove all accessory kits and the
packaging materials.
12
2. RRemove the lengths of wood and the
lath on the front.
13
3. Remove the two wood blocks.
4. Remove the nails and screws from the
board, or knock them flat using a
hammer so that the tyres cannot be
damaged.
5. Push the tractor forwards off the pallet.
LAWN TRACTOR ASSEMBLY
WARNING!
Danger if assembly is not carried out
completely!
Do not operate the tractor (even for a
test) before it has been fully assembled!
Carry out all the work described in the
assembly instructions conscientiously!
If you are uncertain about anything, ask
a specialist to confirm that the
assembly has been carried out correctly
before the machine is started up.
The following assembly jobs must have
been carried out correctly before the tractor
can be taken into operation as described in
the operating instructions:
- mounting of the wheels
- mounting of the steering wheel
- mounting of the operator's seat
GB
