must be connected to sockets marked as C and D. Such way
of connection guarantees proper display of obstacle's position
on the screen.
3. Next, connect power supply cables (red cable protected
with a fuse connect to reverse light lamp, and black cable
to ground); Make a permanent connection using a crimp
connector or by soldering etc.
4. Turn on the vehicle's engine and switch on reverse gear.
5. Once the reverse lights are on, the device will be supplied
with power. If the device has been connected properly,
it will issue a short sound signal and the display will turn
on (after that it will enter AUTO-CHECK mode - automatic
device circuits control mode).
Note: when in condition as presented below, sensors' operation
will be distorted.
