4. Hardware Installation

•
Turn the system power OFF before installation!
•
Use static electricity discharge precautions.
•
Remove the chassis cover from your computer
•
Locate an unused PCI-Express slot (typically white or ivory) and remove the
corresponding slot cover from computer chassis.
•
Plug the RS422/485 PCIe card to the unused PCI-Express expansion slot and
attached the I/O card bracket to the computer chassis screw.
•
Put the chassis cover back on the computer.
•
Turn ON the power of your computer and peripherals.
•
Proceed with Software Driver Installation.
