Sinclair SDV4 Servicehandbuch Seite 303

SDV4-730EA (26HP)-cooling
Combination
Outdoor Air
(%)
temperature(°C
(Capacity
DB)
index)
130 10
130 12
130 14
130 16
130 18
130 20
130 21
130 23
130 25
130 27
130 29
130 31
130 33
130 35
130 37
130 39
130 42
130 44
130 46
120 10
120 12
120 14
120 16
120 18
120 20
120 21
120 23
120 25
120 27
120 29
120 31
120 33
120 35
120 37
120 39
120 42
120 44
120 46
110 10
110 12
110 14
14.00 16.00
TC PI TC PI
kW kW kW kW
64.13 9.78 76.39 11.95
64.13 9.95 76.39 12.18
64.13 10.15 76.39 12.41
64.13 10.32 76.39 12.66
64.13 10.52 76.39 12.92
64.13 10.75 76.39 13.75
64.13 11.03 76.39 14.24
64.13 11.84 76.39 15.27
64.13 12.64 76.39 16.35
64.13 13.49 76.39 17.50
64.13 14.41 76.39 18.70
64.13 15.38 76.13 19.78
64.13 16.38 74.82 20.53
64.13 17.47 73.52 21.27
64.13 18.58 72.47 22.04
64.13 19.78 71.17 22.27
64.13 20.82 70.44 22.49
64.13 21.88 69.70 22.70
64.13 22.94 69.41 22.92
59.18 8.92 70.39 10.89
59.18 9.09 70.39 11.09
59.18 9.26 70.39 11.32
59.18 9.43 70.39 11.55
59.18 9.60 70.39 11.78
59.18 9.80 70.39 12.23
59.18 9.89 70.39 12.66
59.18 10.58 70.39 13.58
59.18 11.29 70.39 14.52
59.18 12.06 70.39 15.52
59.18 12.86 70.39 16.58
59.18 13.72 70.39 17.69
59.18 14.61 70.39 18.87
59.18 15.55 70.39 20.12
59.18 16.55 70.39 21.44
59.18 17.61 70.13 22.64
59.18 18.25 69.38 22.85
59.18 18.47 69.01 23.07
59.18 18.68 68.62 23.28
54.23 8.09 64.66 9.86
54.23 8.26 64.66 10.06
54.23 8.41 64.66 10.24
Indoor temperature(°C WB)
18.00 19.00
TC PI TC PI
kW kW kW kW
88.64 14.21 92.03 14.52
88.64 14.49 90.73 14.44
88.38 14.67 89.68 14.49
87.34 14.61 88.38 14.38
86.03 15.15 87.08 15.24
84.73 15.89 86.03 15.98
84.21 16.27 85.51 16.35
83.16 17.01 84.21 17.09
81.86 17.75 82.90 17.84
80.82 18.50 81.86 18.61
79.51 19.24 80.56 19.35
78.21 20.01 79.51 20.12
77.17 20.75 78.21 20.87
75.86 21.53 77.17 21.64
74.82 22.30 75.86 22.41
73.52 23.04 74.82 23.18
72.75 23.26 74.05 23.40
71.97 23.39 73.28 23.62
71.20 23.69 72.51 23.70
81.87 12.95 87.60 14.01
81.87 13.21 87.60 14.26
81.87 13.46 87.60 14.55
81.87 13.72 87.08 14.66
81.87 14.18 85.78 15.15
81.87 15.26 84.73 15.89
81.87 15.81 83.95 16.26
81.87 16.92 82.91 16.98
80.56 17.67 81.60 17.72
79.51 18.38 80.56 18.50
78.21 19.12 79.26 19.24
76.91 19.89 78.21 19.98
75.86 20.64 76.91 20.75
74.56 21.38 75.61 21.50
73.52 22.15 74.56 22.27
72.22 22.90 73.26 23.04
71.46 23.11 72.51 23.25
70.71 23.28 71.75 23.32
70.10 23.54 70.99 23.69
75.09 11.72 80.30 12.66
75.09 11.95 80.30 12.92
75.09 12.18 80.30 13.15
20.00 22.00
TC PI TC PI
kW kW kW kW
93.07 14.24 95.42 13.64
92.03 14.15 94.11 13.52
90.73 14.06 93.07 13.95
89.42 14.55 91.77 14.69
88.38 15.32 90.73 15.47
87.08 16.07 89.42 16.21
86.55 16.44 88.90 16.61
85.25 17.18 87.59 17.35
84.21 17.95 86.55 18.12
82.90 18.70 85.25 18.90
81.86 19.47 84.21 19.67
80.56 20.21 82.90 20.44
79.51 20.98 81.86 21.21
78.21 21.76 80.56 22.01
77.17 22.56 79.25 22.81
75.86 23.33 78.21 23.58
75.09 23.54 77.44 23.63
73.55 23.61 74.62 23.72
72.93 23.76 73.31 23.80
91.77 14.61 93.86 14.03
90.47 14.52 92.55 13.98
89.16 14.43 91.51 13.89
88.12 14.46 90.21 14.61
86.82 15.21 88.91 15.35
85.78 15.95 87.86 16.09
84.99 16.32 87.34 16.47
83.95 17.07 86.03 17.24
82.65 17.81 84.99 17.98
81.60 18.58 83.69 18.75
80.30 19.32 82.39 19.52
79.26 20.09 81.34 20.29
77.95 20.84 80.04 21.07
76.91 21.61 78.99 21.84
75.61 22.38 77.69 22.61
74.31 23.15 76.65 23.41
73.55 23.37 75.89 23.50
72.79 23.43 73.63 23.58
72.26 23.73 72.87 23.64
85.51 13.64 92.04 14.47
85.51 13.89 91.00 14.41
85.51 14.15 89.69 14.32
24.00
TC PI
kW kW
97.76 13.01
96.46 13.32
95.42 14.09
94.11 14.84
93.07 15.61
91.77 16.38
91.24 16.75
89.94 17.52
88.90 18.29
87.59 19.10
86.55 19.87
85.25 20.67
83.94 21.44
82.90 22.24
81.60 23.07
80.56 23.87
77.47 24.09
75.62 24.19
74.47 24.99
95.94 13.49
94.64 13.41
93.59 13.98
92.29 14.72
91.25 15.49
89.95 16.24
89.43 16.64
88.12 17.38
87.08 18.15
85.78 18.92
84.73 19.69
83.42 20.50
82.12 21.27
81.08 22.07
79.78 22.87
78.74 23.64
75.71 23.88
74.85 24.71
74.20 24.93
94.12 13.98
92.82 13.89
91.78 13.87
