Sinclair SDV4 Servicehandbuch Seite 299

SDV4-680EA (24HP)-heating
Outdoor Air
Combination
temperature(°C
(%)
DB)
(Capacity
°C °C
index)
DB WB
130 -19.8 -20
130 -18.8 -19
130 -16.7 -17
130 -13.7 -15
130 -11.8 -13
130 -9.8 -11
130 -9.5 -10
130 -8.5 -9.1
130 -7 -7.6
130 -5 -5.6
130 -3 -3.7
130 0 -0.7
130 3 2.2
130 5 4.1
130 7 6
130 9 7.9
130 11 9.8
130 13 11.8
130 15 13.7
120 -19.8 -20
120 -18.8 -19
120 -16.7 -17
120 -13.7 -15
120 -11.8 -13
120 -9.8 -11
120 -9.5 -10
120 -8.5 -9.1
120 -7 -7.6
120 -5 -5.6
120 -3 -3.7
120 0 -0.7
120 3 2.2
120 5 4.1
120 7 6
120 9 7.9
120 11 9.8
120 13 11.8
120 15 13.7
110 -19.8 -20
110 -18.8 -19
16 18
TC PI TC PI
kW kW kW kW
49.54 13.28 49.30 14.21
50.27 13.58 50.03 14.50
52.21 14.21 51.97 15.09
54.40 14.87 54.16 15.72
56.59 15.53 56.59 16.36
59.26 16.21 59.02 16.99
60.71 16.55 60.47 17.31
61.92 16.85 61.69 17.58
64.12 17.34 64.12 18.07
67.51 17.99 67.27 18.68
70.67 18.58 70.43 19.24
76.25 19.48 76.25 20.09
82.32 20.29 82.09 20.85
86.45 20.80 86.21 21.34
90.83 21.29 90.58 21.78
95.44 21.73 95.19 22.22
100.29 22.17 100.06 22.61
105.64 22.58 105.39 23.02
110.74 22.98 105.88 21.80
49.30 14.55 49.06 15.41
50.03 14.82 49.79 15.68
51.98 15.41 51.73 16.24
54.16 16.02 53.92 16.80
56.35 16.63 56.35 17.38
59.01 17.26 58.77 17.97
60.48 17.58 60.23 18.29
61.69 17.85 61.44 18.53
63.87 18.31 63.87 18.97
67.27 18.90 67.03 19.53
70.43 19.46 70.43 20.07
76.02 20.29 76.02 20.85
82.09 21.05 81.84 21.56
86.22 21.51 85.97 22.00
90.59 21.95 90.59 22.41
95.21 22.39 94.96 22.83
100.06 22.78 97.63 22.39
103.70 22.56 97.63 21.00
103.70 21.24 97.63 19.78
49.05 15.82 48.82 16.60
49.79 16.07 49.54 16.85
Indoor temperature(°C WB)
20 21
TC PI TC PI
kW kW kW kW
49.06 15.16 49.06 15.63
50.03 15.43 49.78 15.89
51.72 15.99 51.72 16.43
53.92 16.58 53.92 16.99
56.34 17.16 56.10 17.58
58.77 17.77 58.77 18.17
60.23 18.07 60.23 18.46
61.69 18.34 61.44 18.70
63.87 18.78 63.87 19.14
67.02 19.36 67.02 19.70
70.43 19.87 70.18 20.22
76.01 20.68 76.01 20.90
81.84 21.41 81.84 21.68
86.21 21.85 85.97 22.12
90.58 22.29 90.34 22.54
95.19 22.68 94.96 22.93
99.57 22.90 96.17 22.00
99.57 21.46 96.17 20.61
99.57 20.22 96.17 19.44
48.81 16.28 48.81 16.70
49.79 16.53 49.55 16.95
51.41 17.04 51.49 17.46
53.67 17.58 53.67 18.00
56.11 18.14 56.11 18.53
58.77 18.70 58.53 19.07
59.99 18.97 59.99 19.34
61.44 19.21 61.20 19.56
63.63 19.63 63.63 19.97
66.78 20.17 66.78 20.48
70.19 20.66 70.19 20.95
75.77 21.39 75.77 21.68
81.84 22.07 81.60 22.34
85.97 22.49 85.73 22.73
90.35 22.88 88.89 22.56
91.80 22.07 88.89 21.20
91.80 20.75 88.89 19.95
91.80 19.46 88.89 18.73
91.80 18.36 88.89 17.65
48.57 17.41 48.57 17.80
49.54 17.63 49.54 18.02
22 24
TC PI TC PI
kW kW kW kW
48.82 16.09 48.82 17.04
49.78 16.33 49.54 17.26
51.72 16.87 51.49 17.75
53.67 17.43 53.67 18.29
56.10 17.99 55.85 18.80
58.77 18.56 58.53 19.34
59.98 18.82 59.98 19.58
61.44 19.07 61.20 19.83
63.63 19.48 63.38 20.22
66.79 20.02 66.79 20.70
70.18 20.53 69.94 21.17
75.77 21.29 75.77 21.88
81.84 21.97 81.60 22.51
85.97 22.39 85.73 22.90
90.34 22.78 86.70 21.88
93.01 22.44 86.70 20.56
93.01 21.09 86.70 19.36
93.01 19.80 86.70 18.17
93.01 18.65 86.70 17.14
48.81 17.14 48.57 18.02
49.55 17.38 49.30 18.24
51.49 17.87 51.24 18.68
53.67 18.38 53.43 19.17
55.86 18.90 55.86 19.65
58.53 19.41 58.29 20.14
59.99 19.68 59.75 20.39
61.20 19.92 60.96 20.61
63.39 20.29 63.39 20.95
66.78 20.80 66.55 21.41
69.95 21.27 69.95 21.85
75.53 21.95 75.53 22.51
81.60 22.58 79.90 22.46
85.73 22.98 79.90 21.10
85.97 21.63 79.90 19.85
85.97 20.34 79.90 18.68
85.97 19.14 79.90 17.60
85.97 18.00 79.90 16.55
85.97 16.97 79.90 15.63
48.59 18.19 48.33 19.00
49.30 18.41 49.30 19.19
