Instructions for use
1. Place the fan on a flat, firm surface.
2. Route the mains lead so that there is no risk of anyone tripping over it and connect the plug
to an electrical outlet.
3. Use the control (2) to select the fan speed.
4. Turn the oscillation function on/off by moving the control (1) up/down.
Tilting the fan head backwards
Loosen the knob (9), tilt the fan head to the desired angle and
then tighten the knob.
Remember that the fan head can only be tilted as far as
the locking screw (3) permits.
Care and maintenance
•
Unplug the mains lead from the electrical outlet before cleaning.
•
Clean the product using a lightly moistened cloth. Use only mild cleaning agents, never
solvents or corrosive chemicals. Vacuum them if necessary.
•
If the fan is not to be used for an extended period, it should be unplugged and stored in a dry
place out of the reach of children.
Responsible disposal
This symbol indicates that this product should not be disposed of with general
household waste. This applies throughout the entire EU. In order to prevent any
harm to the environment or health hazards caused by incorrect waste disposal,
the product must be handed in for recycling so that the material can be disposed of
in a responsible manner. When recycling the product, take it to your local collection
facility or contact the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
Rated voltage 220–240 V AC,
50/60 Hz
35 W
Power
55 cm
Height
Fan head
35 cm
diameter
Mains lead
177 cm
Weight
3.7 kg
Description
Max fan flow rate
Fan power input
Service value
Standby power consumption
Fan sound power level
Maximum air velocity
Measurement standard for
service value:
6
Symbol
Value
Unit
F
35.3
m³/min
P
32.36
W
SV
1.09
(m³/min)/W
P
0
W
SB
LwA
55.8
dB(A)
c
1.73
metres/sec
IEC 60879:1986 (corr.1992)
